Webinar ICEE ITB 2023 sesi 2 - Green Design Building with ArchiCAD (part 2 - end)





Apa yang ditawarkan oleh ArchiCAD dalam konsep GDB? (Objectives GBD in ArchiCAD)

- Estimates the building's primary energy demands issue energy performance reports

- Analysize which part contributes the heaviest to the energy consumption

- Compare design option and optimize (clash detection?)



Parameter 1 : SUSTAINABLE SOLUTION NEED

1) Schematic design (massing, orientation, zoning, building materials)

2) Design developing (low energy building design)

3) Construction documents (bulding model data export to 3rd party calculator software and building energy performance rating standard doc)

Parameter 2 : ENERGY ANALYSIS WORKFLOW

- model preparation

- energy-related data input (all about the building model)

- convert to BEM (building energy model) generation

- baseline design (energy performance evaluation)



Goal 1 : improved design (berarti design lama diperbaiki)

Goal 2 : improved BEM --> baseline (BEM export for certification)

Goal 3 : energy performance evalution (design option) --> baseline design dari goal kedua

Di ArchiCAD ada fitur Environmental Inputs, jadi kita input longitude dan latitude dari server (to do the energy calculation), masuk ke database mereka, jadi bisa kita pakai data iklim/temperature seperti climate data, wind protection, jadi ada informasi part protected



Thermal blocks : if a thermal block for meeting room,

Jadi, Archicad punya setting untuk memasukkan data (juga menyediakan data default) tentang human heat, service hot-water, humidity lead, etc. Archicad akan melakukan analisa building geometry, material dan openings ketika melakukan generates pada model melalui space boundaries-nya
